Install New Belt. Install the new belt by fishing it up through that hole in the frame, where you just removed the old belt. Then pull the left side of the belt over and down through the notch in the frame. Route the new belt over the loose steering tie rods, through the guide (17) and onto the upper pulley (27) under the engine. Service Schedule Parts for a John Deere LT166 Lawn Tractor & Parts List. While your John Deere machine is certainly built with quality parts, they have a limited life. Good news is you can easily service your machine yourself using a John Deere maintenance kit or service kits or by getting the specific John Deere part needed to keep your John Deere mower or tractor running for a long time.
